KEYPLUS P101 Magnetic Mounting Pad

Instant, Drill-Free Magnetic Mounting Kit for Smart Alarms & Sensors

KEYPLUS P101 Magnetic Mounting Pad

The KEYPLUS P101 is an industrial-grade drill-free magnetic mounting pad engineered for fast, damage-free sensor deployment. Powered by authentic 3M 9448A double-coated tissue tape and 72-hour galvanized zinc steel plates, it securely supports devices up to 650g without drilling, screws, or wall anchors. Ideal for smoke detectors, heat alarms, carbon monoxide monitors, and IoT multi-sensors, it eliminates installation mess while enabling swift, toolless maintenance.

Overcoming Tedious Installation and Premature Detachment Risks

• Time-Consuming & Messy Ceiling Drilling: Conventional bracket mounting requires drills, ladders, and wall anchors, generating airborne masonry dust that clogs optical sensing chambers and damages finished ceilings. The P101 installs in under 10 seconds with simple peel-and-stick deployment, slashing batch retrofit labor by over 80%.
• Accidental Drops & Humidity Degradation: Cheap adhesive foam tapes degrade under temperature fluctuations and moisture, leading to fallen alarms and damaged hardware. The P101 combines genuine high-tack 3M 9448A adhesive with a broad 74.5mm base to disperse shear stress, reliably maintaining hold up to 650g.

Authentic 3M 9448A High-Shear Adhesive Base

• Feature: Both mounting discs are pre-fitted with precision die-cut 3M 9448A industrial pressure-sensitive adhesive layers.
• Advantage: Establishes rapid, durable bonding across diverse smooth and semi-porous substrates, including drywall, painted concrete, wood, metal, and plastic.
• Benefit: Guarantees zero unprovoked detachment risks, preventing hardware damage claims and maintenance callbacks across hospitality and multi-family portfolios.

Dual Magnetic Interlocking Architecture

• Feature: High-grade permanent neodymium magnets paired with an anti-slip galvanized steel keeper plate rated for loads up to 650g.
• Advantage: Delivers instant self-centering magnetic capture while allowing smooth lateral slide-off when servicing is required.
• Benefit: Enables quick, toolless one-handed removal for periodic chamber cleaning, functional testing, or battery replacement without peeling off the base tape.

72-Hour Galvanized Zinc Surface Protection

• Feature: Heavy-duty cold-rolled steel base plates treated with a rigorous 72-hour electro-galvanized anti-corrosion finish.
• Advantage: Resists environmental oxidation, rust blistering, and galvanic degradation in damp kitchens, basements, and humid utility rooms.
• Benefit: Matches the 10-year statutory service lifespan of modern commercial smoke detectors, ensuring structural integrity throughout project lifecycles.

Model Number	P101
Product Category	Accessories & Modules / Power & Installation Accessories (Mounting Kit)
Disc Diameter	Ø 74.5 mm (2.93 in)
Combined Thickness	Approx. 4.0 – 4.5 mm (Mated Pair)
Adhesive Specification	Genuine 3M 9448A Double-Coated Tissue Tape
Surface Treatment	72-Hour Galvanized Zinc Anti-Rust Coating
Rated Load Capacity	Up to 650 g (1.43 lbs)
Magnet Configuration	Dual High-Power Neodymium (NdFeB) Permanent Magnets
Compatible Devices	Standalone Smoke Alarms, Heat Detectors, CO Alarms, IoT Multi-Sensors (Ø ≥ 70mm)
Applicable Substrates	Drywall, Plasterboard, Smooth Concrete, Finished Wood, Metal Panels, Ceramic Tiles
Operating Temperature	-10°C to +55°C (Short-term tolerance up to 70°C)
Net Weight	Approx. 48 g per pair

Flexible Packaging Configurations for OEM & Engineering Contractors

• Retail Blister Packaging: 1 pair per sealed blister card with step-by-step visual installation manual, ready for retail display.
• Contractor Bulk Pack: 10 pairs per protective inner carton; 200 pairs per master export carton (Carton Dimensions: 420 × 320 × 260 mm, Gross Weight: ~11.5 kg).
• OEM Customization: Custom backing paper printing, branded outer box design, and custom diameter configurations available upon request.
• Fulfillment & Lead Time: Sample dispatch within 3–5 business days; commercial batch orders delivered in 15–25 business days.
